AXE-PROCABLE18x1.5

Male cable SCHUKO 16A/230V BLACK

Order number 7372
EAN/pcs 4024941852401
Product Group Domestic plug with MULTI-GRIP cable gland
Amperage 16A
Poles 3p (2P+PE)
Voltage 250V
Frequency alternating current (AC)
Protection IP44
Color code black RAL 9005
Connection Design Screw Terminal
Max. conductor 4,0 mm²
Belgian/French standaard ! PEN EARTH !!

Declaration of Conformity

Female cable rubber

Volrubber koppelcontactstop 16A, 250V~ 2 polig met penaarde
(conform NBN C 61-112-1).

kleur : zwart
gewicht : 150 g

Eigenschappen:

• slijtvaste, olie- en zuurbestendige massief rubber mantel
• ontwikkeld voor zwaar industrieel gebruik
• zeer drukbestendig, vormvast rubber binnenwerk
• montagevriendelijk door wegklapbare trekontlasting
• vernikkelde contacten
• schroeven met kombi-kop
• reeds geopende contacten
• IP44 stof- en spatwaterdichte kabelinvoer
• geschikt voor neopreenkabel van 3 x 2,5 mm²

Insert Male 16E with screw contacts

Artikelnummer 09 33 016 2601 Beschrijving Han E MALE INSERT SCREW Type sheet PDFPDF Identification Category Inserts Series Han E® Termination method Screw termination Version Gender Male Size 16 B With wire protection Yes Number of contacts 16 PE contact Yes Technical characteristics Conductor cross-section 0.75 ... 2.5 mm² Electrical data acc. to IEC 61984 16 A 500 V 6 kV 3 Rated current 16 A Rated voltage 500 V Rated impulse voltage 6 kV Pollution degree 3 Rated voltage acc. to UL 600 V Rated voltage acc. to CSA 600 V Contact resistance ? 1 m? Limiting temperature -40 ... +125 °C Tightening torque 0.5 Nm Mating cycles ? 500 Material properties Material (insert) Polycarbonate Colour (insert) RAL 7032 (pebble grey) Net weight 85.8 g RoHS compliant with exemption Specifications and approvals Specifications IEC 61984 EN 60664-1 Approvals CSA-C22.2 No. 182.3 PVVA8.E318390 UL 1977 ECBT2.E235076 UL 2237 PVVA2.E318390 GL Yes

Declaration of Conformity

Insert Female 16E with screwcontacts

Han 16E-bu-s Part number 09 33 016 2701 Specification Han 16E-bu-s HARTING eCatalogue https://b2b.harting.com/09330162701 Identification Category Inserts Series Han E® Version Termination method Screw termination Gender Female Size 16 B With wire protection Yes Number of contacts 16 PE contact Yes Technical characteristics Conductor cross-section 0.75 ... 2.5 mm² Conductor cross-section AWG 18 ... AWG 14 Rated current 16 A Rated voltage 500 V Rated impulse voltage 6 kV Pollution degree 3 Rated voltage acc. to UL 600 V Rated voltage acc. to CSA 600 V Insulation resistance >1010 O Contact resistance =1 mO Limiting temperature -40 ... +125 °C Stripping length 7.5 mm Product data sheet 09 33 016 2701 Han 16E-bu-s Page 2 / 2 | Creation date 2019-10-01 | Please note that the data specified here were taken as extracts from the online catalogue. Please refer to the user documentation for the complete and up-to-date information and data. Please also note that the user is responsible for validating functionality, conformity with applicable laws and directives, as well as for the electrical safety in the particular application. HARTING Electric GmbH & Co. KG | Wilhelm-Harting-Straße 1 | 32339 Espelkamp | Germany Phone +49 5772 47-97100 | electric@HARTING.com | www.HARTING.com Technical characteristics Tightening torque 0.5 Nm Mating cycles =500 Material properties Material (insert) Polycarbonate Colour (insert) RAL 7032 (pebble grey) Material (contacts) Copper alloy Surface (contacts) Silver plated Material flammability class acc. to UL 94 V-0 RoHS compliant with exemption RoHS exemptions 6(c): Copper alloy containing up to 4 % lead by weight ELV status compliant with exemption China RoHS 50 REACH Annex XVII substances No REACH ANNEX XIV substances No REACH SVHC substances Yes REACH SVHC substances Lead Specifications and approvals Specifications EN 60664-1 IEC 61984 Approvals DNV GL UL / CSA UL 1977 ECBT2.E235076 UL 2237 PVVA2.E318390 CSA-C22.2 No. 182.3 PVVA8.E318390 Commercial data Packaging size 1 Net weight 89 g Country of origin Germany European customs tariff number 85366990 eCl@ss 27440205 Contact insert for industrial connectors
