Panel Open 6E/24DD - 1Lever-Grey
Artikelnummer 09 30 006 0301
Beschrijving Han E BULKHEAD HOUSING
Type sheet PDFPDF
Identification
Category
Hoods/Housings
Series of hoods/housings
Han® B
Type of hood/housing
Bulkhead mounted housings
Type
Low construction
Locking type
Single locking lever
Han-Easy Lock®
Yes
Version
Size
6 B
Field of application
Standard hoods/housings for industrial connectors
Technical characteristics
Limiting temperature
-40 ... +125 °C
Degree of protection acc. to IEC 60529
IP65
Degree of protection acc. to UL 50
12
4
4X
Flammability acc. to UL 94 (locking levers)
V-0
Material properties
Material (hood/housing)
Aluminium die-cast
Surface (hood/housing)
Powder-coated
Colour (hood/housing)
RAL 7037 (dust grey)
Material (seal)
NBR
Material (locking)
Stainless steel
Polycarbonate
Colour (locking)
RAL 7037 (dust grey)
Net weight
89.8 g
RoHS
compliant
Specifications and approvals
Approvals
UL 1977 ECBT2.E235076
CSA-C22.2 No. 182.3 ECBT8.E235076
GL
Yes
Declaration of Conformity
