M6 cagenut (wide slot - 2 mm) for 6150 (aluminium rear rail punched)

Declaration of Conformity

Combi cable XLR3 black + PowerCON split: 25cm / 100m

Cable : Syntax Combi cable Connector : Neutrik Powercon Accesories : Transparent Heat Shrink x 2

Male cable SCHUKO 16A/230V BLUE

Order number 7370
EAN/pcs 4024941852388
Product Group Domestic plug with MULTI-GRIP cable gland
Amperage 16A
Poles 3p (2P+PE)
Voltage 250V
Frequency alternating current (AC)
Protection IP44
Color code blue RAL 5015
Connection Design Screw Terminal
Max. conductor 4,0 mm²
Belgian/French standaard ! PEN EARTH !!

Declaration of Conformity

etherCON CAT6_A cable connector self-termination, nickel plating

etherCON CAT6A cable connector self-termination, for insulation diameter > 1.1 mm, nickel plating The set NE8MX6 consists of a cable plug carrier offering a robust metal shell, proven Neutrik chuck-type strain relief and a CAT6A compliant RJ45 plug. The set is suitable for a cable diameter range of 7 mm to 9.5 mm and wire gauge of AWG26/1 - AWG22/1 (solid) or AWG27/7 - AWG22/7 (stranded). Attention! Does not intermate with the CAT6 chassis connectors NE8FDY-C6 and NE8FDY-C6-B. Features & Benefits •Ruggedized connector with CAT6A component compliance according to ISO/IEC 11801 and TIA/EIA 568-C.2 •PoE+ compliant according to 802.3at Type2 •IP65 protected when mated with NE8FDX-P6-W or NE8FDX-Y6-W •Rugged latch lock system million fold proven •Intermateable with the existing etherCON CAT5 range •Unique Neutrik chuck-type strain relief
