NEU-NAC3FC-HC

Cable Speakon, 4P , Female

4 pole cable connector, chuck type strain relief, dark grey bushing The industry-standard for loudspeaker connections offer extremely reliable and robust cable connectors with a reliable locking system. They feature solid contacts with screw-type terminals including a stranded wire protection which offer also solder termination. Features & Benefits •Current rating 40 A rms continuous •Up to 50 A audio signal, duty cycle 50% •Only 3 parts, easy to assemble •High impact materials - long-lasting and reliable •Easy and extremely precise locking system "Quick Lock" •Improved grip on latch •1 piece strain relief, chuck for 7 to 14.5 mm cable O.D. •Color coding possible •Improved screw-type termination for highest pull-out force •Integrated design guarantees "Made by Neutrik®"

Aansluitsnoer 3M 3G2,5 + ST

Cable Speakon 4P, Male, Heavy duty, Metal, Nickel

4 pole male cable connector, metal housing, chuck type strain relief The speakON STX Series was especially designed for heavy duty amplifier-loudspeaker applications like professional touring. The extremely rugged and durable STX Series features an all metal housing. Features & Benefits •Current rating 40 A continuous, 50 A audio signal with 50% duty cycle •Robust and durable all metal housing •Sealing ring provides weatherproof IP54 rating in mated condition •Reinforced metal quick lock system for ease and precise locking •Extra large solder contacts for up to 6mm² (AWG10) wires •Mate with all available speakON products

Female Panel 419, gold cont (-ring)

The SYNTAX® SSX series, designed for professional applications and perfectly compatible with standard Socapex 419 series, is extremely robust being made of thick wall construction machined aluminium alloy, with a hard black anodized finish or black painted finish. The contacts insert is chloroprene rubber, which enables the use of removable contacts, either crimp or solder version. The unit is completely IP67 watertight when mated. Electrical safety and compliance is guaranteed by internal insulation of the shells, obtained through a safety insulating sleeve to prevent electric shock, as well as “first make last break” ground contacts. Grounding rings allow bussing of the ground contacts. Locking rings and backshells are designed for easy handling.
