NEU-NP2X-B

Panel CAT5e feedthrough, D-shape, Black housing

RJ45 feedthrough receptacle, black D-shape metal flange with the latch lock, mounting screws included The etherCON Series is a ruggedized and lockable RJ45 connector system, optimized for pro audio, video and lightning network applications. The chassis connectors are shaped to fit into standardized panels out of the entertainment industry. The D-Series offers the most rugged design of the etherCON series and is perfectly suitable for panel mount and the installer market. Attention! Does not intermate with CAT6 cable connector NE8MC6-MO and NKE6S* cables. Features & Benefits •Accommodates NE8MC* or any standard RJ45 plug •Approved latch lock system •Mountable from the front or rear of the panel •Complies with Cat 5e according to TIA / EIA 568B and ISO / IEC 11801 standard

Cable connector carrier consisting of black chromium shell, fixing disk, chuck and boot

Cable connector carrier consists of a black chromium shell, fixing disk, chuck and boot. The boot (same as X-Series) is suitable for cable diameters from 3.5 - 8 mm. For non preassembled cables only. Cable connector carrier does not include a RJ45 plug. The etherCON cable connector carrier upgrades a conventional RJ45 connector to an extremely robust lockable solution. Attention! Does not intermate with the CAT6 chassis connectors NE8FDY-C6 and NE8FDY-C6-B. Features & Benefits •The RJ45 system for harsh and demanding environment •Cable connector carrier accepts the most common RJ45 plugs (see list at downloads) •Rugged diecast shell and unique chuck type strain relief •Protects Ethernet connections in a variety of commercial type applications and is designed to prevent breakage of the fragile components of standard RJ 45 connectors •O-ring gasket to achieve IP54 water protection in combination with SE8FD sealing kit •Accessories include color coded boots in 9 standard colors

AUDIO MULTI 4 PAIRS

The SYNTAX® AUDIO MULTIPAIR cables are developed for high-standard professional applications in the rigorous environments of the audio & video installations, studio recording and musical entertainment, everywhere excellent electrical and mechanical properties are required. The pairs are twisted and jacketed; the external PVC jacket of each pair is individually numbered. All jacketed pairs are inside an outer PVC sheath whose internal talc dusted lined ridges allow the cores to slide against one other, yet maintain them properly clustered even under heavy usage and continuous rewinding. This solves the problems of twisting and knotting of the cores while keeping the right cable flexibility. The XLPE conductor insulation is particularly resistant to high temperatures, so as to avoid warping or shrinkage when soldering. The aluminium/polyester foil shield provides a 100% screen and the drain wire inside allows fast installation. All the conductors are made of High Purity Oxigen Free Copper. The extra-flexible PVC external jacket is anti-trampling and anti-scratch for usage at either extremely low or high temperatures, ranging from -30°C up to +70°C.

Cable Female 3P, Black body, gold contacts

3 pole female cable connector with black metal housing and gold contacts. The next generation of the worldwide accepted standard of XLR cable connectors. The successor of the X series offers several new features which make it more reliable, easier to assemble and improves contact integrity as well cable strain relief. Features & Benefits Unique cage design of female contact for low contact resistance and high integrity Female contact incorporates a solder barrier to prevent solder running into the contact mating area Female connector with improved solid metal latch which is larger and easier to handle Additional ground spring contacts for better shell ground continuity Improved chuck type strain relief provides higher pull-out force and makes assembly easier and faster Boot with polyurethane gland gives high protection to cable bending stresses Colored rings and boots available for coding or identification Sleek and ergonomic design - valuable and handy Rugged zinc diecast shell, longlasting and dependable Internal thread on shell is well protected against any damage Branded with unique hologram - guarantees genuine and authentic Neutrik product
