NEU-NP2X-BAG

Patch cable SC-Isopod SO-F22; 2 x 0,22 mm²; PVC Ø 3,30 mm; orange

Technical Data: - Properties: Analog - Properties: OFC oxygen free copper - Application area: Installation - Application: Patch cable - Colour: orange - Colour detailed: orange - Signal transmission: symmetrical - Jacket material: PVC - Jacket Ø: 3,3 mm - Number of Channels (audio): 1 - Inner conductor (audio): 2 - Inner conductor (audio): 0,22 mm² - Inner conductor Ø (audio): 0,53 mm - AWG (audio): 24 - Shielding: AL / PT foil + AL / PT foil + filler strand, tin-plated - Copper strands (audio): 7 - Copper strand Ø (audio): 0,20 mm - Conductor insulation material: PE - Conductor insulation Ø: 1,12 mm - Weight per 1 m: 16 g - Fire load per m: 0,05 kWh - Style variant: round - Shielding factor: 100 % - Packing: 200 m spool - Temperature min.: -25 °C - Temperature max.: 70 °C - Width: 3,3 mm - Height: 3,3 mm - Capac. cond./cond. per 1 m (audio): 74 pF - Capac. cond./shield. per 1 m (audio): 143 pF - Insulation resist. per 1 km: 0,2 GΩ - Insulation resist. per 1 km (audio): 0,2 GΩ - Conductor resistance per 1 km: 88 Ω - Shield. resistance per 1 km: 75 Ω Only available on full 200m lenghts

Rubber Feet 38*10mm

Product type Feet and Skids Type Feet round Material Soft PVC with PP core Colour Black Diameter 38 mm Height 10 mm Mounting hole diameter 6.5 mm stackable no Recessed steel disc yes Weight 0,015 kg

Declaration of Conformity

Cable Speakon, 4P , Female

4 pole cable connector, chuck type strain relief, dark grey bushing The industry-standard for loudspeaker connections offer extremely reliable and robust cable connectors with a reliable locking system. They feature solid contacts with screw-type terminals including a stranded wire protection which offer also solder termination. Features & Benefits •Current rating 40 A rms continuous •Up to 50 A audio signal, duty cycle 50% •Only 3 parts, easy to assemble •High impact materials - long-lasting and reliable •Easy and extremely precise locking system "Quick Lock" •Improved grip on latch •1 piece strain relief, chuck for 7 to 14.5 mm cable O.D. •Color coding possible •Improved screw-type termination for highest pull-out force •Integrated design guarantees "Made by Neutrik®"

Rubber Feet 38*20mm

Product type Feet and Skids Type Feet round Material Soft PVC with PP core Colour Black Diameter 38 mm Height 20 mm Mounting hole diameter 6.5 mm stackable no Recessed steel disc yes Weight 0.03 kg

Declaration of Conformity
