TLG-J00026A0165

Panel CAT5e feedthrough, D-shape, Black housing

RJ45 feedthrough receptacle, black D-shape metal flange with the latch lock, mounting screws included The etherCON Series is a ruggedized and lockable RJ45 connector system, optimized for pro audio, video and lightning network applications. The chassis connectors are shaped to fit into standardized panels out of the entertainment industry. The D-Series offers the most rugged design of the etherCON series and is perfectly suitable for panel mount and the installer market. Attention! Does not intermate with CAT6 cable connector NE8MC6-MO and NKE6S* cables. Features & Benefits •Accommodates NE8MC* or any standard RJ45 plug •Approved latch lock system •Mountable from the front or rear of the panel •Complies with Cat 5e according to TIA / EIA 568B and ISO / IEC 11801 standard

Heat shrink glue 19,0mm Black, 3/1, H5

H-2(3X)
Thin-wall heat shrink tubing / flexible / flame retardant / 3:1

Features:
• Crosslinked Polyolefin
• Shrink ratio: 3:1
• Flame retardant
• General purpose
• High flexibility

Approvals:
• UL224 125 °C VW-1 600 V file E204071
• CSA file no.: 1934614
• Meets: RoHS, Sony-SS-00259

Application:
• Operating temperature: -55 °C to +125 °C
• Minimum shrink temperature: +70 °C
• Minimum full recovery temperature: +100 °C
• Longitudinal change: 0 ± 10% max.
Order information:

• Color: black
• Other colors: red, blue, yellow, green, white, transparent (flame retardant class 2)

Alu housing Length 152mm / Width 82mm / Height 50mm/Black empty box

Bimboxes - BIM 5000 Series Multi Purpose Diecast Boxes
The BIM range of aluminium diecast boxes available in six sizes, each
having slots for holding 1.5mm printed circuit boards.
The boxes have close fitting flanged lids held by M3 screws running into
tapped holes, and thus fully screened enclosures which withstand
temperatures as high as 260ºC (500ºF).
The boxes can be easily drilled or punched and are ideal for both prototype
and production applications.

Female cable SCHUKO 16A/230V BLACK (Special: DE/NL standard) + cover

Order number 748809
EAN/pcs 4024941854030
Product Group Domestic connector with MULTI-GRIP cable gland
Amperage 16A
Poles 3p (2P+PE)
Voltage 250V
Frequency alternating current (AC)
Protection IP54
Color code black RAL 9005
Connection Design head-Screw Terminal
Max. conductor 4,0 mm²
Further Information
Additional technical information With child protection (Shutter)
MULTI-GRIP cable gland with gasket and integrated strain relief
With self-closing hinged lid
Material
Material of Enclosure Polyamide
Contact / Contact Carrier contact carrier made of Polyamide, contacts are brass nickel plated
Weight/pcs 0.093 kg
Packaging unit 20 pcs

Declaration of Conformity
