OMN-OC1266D

Microphone Cable SC-Primus; 2 x 0,50 mm²; PVC Ø 6,50 mm; black

Technical Data: - Properties: OFC oxygen free copper - Properties: Analog - Application area: Stage / live - Application area: Mobile outdoor / indoor - Application area: ELA 100 V - Application area: Installation - Application area: Studio / Broadcast - Application: Microphone Cable - Colour: black - Colour detailed: black - Signal transmission: symmetrical - Jacket material: PVC - Jacket Ø: 6,5 mm - Number of Channels (audio): 1 - Inner conductor (audio): 2 - Inner conductor (audio): 0,50 mm² - Inner conductor Ø (audio): 0,80 mm - AWG (audio): 20 - Shielding: Copper spiral sleeve tin-plated + metalic fleece - Copper strands (audio): 28 - Copper strand Ø (audio): 0,15 mm - Conductor insulation material: PE - Conductor insulation Ø: 1,65 mm - Weight per 1 m: 53 g - UV-resistant: yes - Fire load per m: 0,23 kWh - Style variant: round - Shielding factor: 100 % - Packing: 500 m spool - Packing: 100 m spool - Temperature min.: -25 °C - Temperature max.: 70 °C - Width: 6,5 mm - Height: 6,5 mm - Capac. cond./cond. per 1 m (audio): 80 pF - Capac. cond./shield. per 1 m (audio): 145 pF - Insulation resist. per 1 km: 1 GΩ - Insulation resist. per 1 km (audio): 1 GΩ - Conductor resistance per 1 km: 37 Ω - Shield. resistance per 1 km: 27 Ω

Microphone cable 3P/ Neutrik FMC/MDLXBAG/FDLXBAG/ DRUM/ 100m

Cable : Sommercable Microphone cable Connector : Neutrik XLR connectors Accesories : Transparent Heat Shrink x 2

Cable Speakon, 4P , Female

4 pole cable connector, chuck type strain relief, dark grey bushing The industry-standard for loudspeaker connections offer extremely reliable and robust cable connectors with a reliable locking system. They feature solid contacts with screw-type terminals including a stranded wire protection which offer also solder termination. Features & Benefits •Current rating 40 A rms continuous •Up to 50 A audio signal, duty cycle 50% •Only 3 parts, easy to assemble •High impact materials - long-lasting and reliable •Easy and extremely precise locking system "Quick Lock" •Improved grip on latch •1 piece strain relief, chuck for 7 to 14.5 mm cable O.D. •Color coding possible •Improved screw-type termination for highest pull-out force •Integrated design guarantees "Made by Neutrik®"

TRAY FOR OC866D, OC868D, OC1266D AND OC1268D

• interior dimensions: 500mm x 350mm x 150mm • exterior dimensions: 550mm x 350mm x 160mm • weight: 3kg • produced with 9,5mm birch plywood with phenolic coating on two sides • fits OC866D, OC868D, OC1266D and OC1268D • professional finishing • made in Belgium • all dimensions are approximate
